Application:Â Indoor and outdoor, LED Display Screen
Color: Full Color
Panel Size:Customized
Pixel Pitch:Customized
Model Number:TB8
Brand Name:Novastar
Product Name:Media Player Controller TB8 LED Display Video Processor
Brand:Novastar
MOQ:1 Set
Support:HD Videos
Loading Capacity:2,300,000 pixels
Packaging & Delivery
Selling Units:Single item
Single package size:27.8X13.9X4.5 cm
Single gross weight:1.400 kg
Lead Time :
Quantity(Sets)
1 – 1
>1
Est. Time(days)
7
To be negotiated
Products Description
Novastar Taurus Series Media Player Controller TB8 LED Display Video Processor
Taurus series products are NovaStar’s second generation of multimedia players dedicated to full-color LED displays,can be widely used in LED commercial display field, such as bar screen, chain store screen, advertising machine, mirror screen, retail store screen, door head screen, on board screen and the screen requiring no PC.
Features
Synchronization mechanism for multi-screen playing
Powerful processing capability
Comprehensive control plans
Synchronous and asynchronous dual-mode
Dual-Wi-Fi mode
If the user has a high demand on synchronization, the time synchronization module is recommended. For details, please consult our technical staff.
In addition to solution publishing and screen control via PC, mobile phones and LAN, the comprehensive control plans also support remote centralized publishing and monitoring.
Other Hardware Features
4 Ethernet ports, loading capacity of each port up to 2,300,000 pixels, with the maximum width of 4096 pixels and maximum height of 1920 pixels
Wired Gigabit Ethernet
Stereo audio output
HDMI Loop
HDMI input and auto full-screen display
2 USB ports allowing for USB playback
Onboard light sensor connector allowing for automatic and scheduled brightness adjustment
Applications
Classification
Description
Market type
Advertising media: To be used for advertising and information promotion including bar screen and advertising machine.
Digital signage: To be used for signage display in retail stores including retail store screens and door head screens. Commercial display: To display commercial information of hotel, cinema and shopping mall, such as chain store screens.
Networking mode
Independent screen: Use a PC or mobile client software to enable single-point connection and management of a screen.
Cluster screen: Use the cluster solution developed by NovaStar to realize centralized management and monitor of multiple screens.
Connection type
Wired connection: A PC connects to Taurus through the Ethernet cable or LAN.
Wi-Fi connection: PC, Pad and mobile phone can connect to Taunus through Wi-Fi, which can be enabled in the case without PC in conjunction with ViPlex software.
Specifications
Electrical Parameters
Input voltage
100 V–240 V AC
Maximum power consumption
20W
Storage Space
Operating memory
2 GB
Internal storage space
8 GB on-board with 4 GB available for users
Storage Environment
Temperature
-40ºC–80ºC
Humidity
0% RH–80% RH, non-condensing
Operating Environment
Temperature
-20ºC–60ºC
Humidity
0% RH–80% RH, non-condensing
Packing Information
Dimensions (H×W×D)
375 mm × 280 mm × 108 mm
List
1 × TB8
2 × Wi-Fi omnidirectional antenna
1 × AC power cord
1 × Quick Start Guide
Dimensions (H × W × D)
278.5 mm × 139.5 mm × 45.0 mm
Net Weight
1352.3 g
IP Rating
IP20
Please prevent the product from water intrusion and do not wet or wash the product
